HDPE - 高密度聚乙烯管
商品說明： We’ve been a manufacturer of high quality, HDPE pipes since 1990.
The experience shows evidence that HDPE pipes offer an optimal solution to most pipe needs.

Here at Toford, we insist on using top quality HDPE 100 material for our pipes , for its superior strength, durability, flexibility and UV resistance.

HDPE100 Pipe specifications


  Wall Thickness (mm) Standard Colors
O.D. SDR33 SDR21 SDR17 SDR13.6 SDR11 Black Orange
32mm - - 2.4 2.4 2.9 + +
40mm - - 2.4 2.9 3.6 + +
50mm - - 2.9 3.7 4.5 + +
63mm - - 3.7 4.6 5.7 + +
75mm 2.3 3.6 4.4 5.5 6.8 + +
90mm 2.8 4.3 5.3 6.6 8.2 + +
110mm 3.4 5.3 6.5 8.1 8.2 + +
125mm 3.9 6.0 7.4 9.2 10.0 + +
140mm 4.3 6.7 8.2 10.3 12.7 + +
160mm 4.9 7.7 9.4 11.8 14.5 + +
180mm 5.5 8.6 10.6 13.2 16.4 + +
200mm 6.2 9.6 11.8 14.7 18.2 +
225mm 6.9 10.8 13.2 16.5 20.5 +
250mm 7.7 11.9 14.7 18.4 22.7 +
280mm 8.6 13.4 16.5 20.6 25.5 +
315mm 9.7 15.0 18.5 23.2 28.6 +
355mm 10.9 16.9 20.9 26.1 32.3 +
400mm 12.3 19.1 23.5 29.4 36.4 +
450mm 13.8 21.5 26.5 33.1 40.9 +
500mm 15.3 23.9 29.4 36.8 45.5 +
560mm 17.2 26.7 32.9 41.2 50.9 +
630mm 19.3 30.0 37.1 46.3 57.3 +
710mm 21.8 33.9 41.8 52.2 64.5 +
